Regeneration Banguet Trolley
BBQ10/20
These robust Banqueting trolleys provide a large capacity, mobile, chilled food regeneration solution for Bulk food. Available in two models 10 or 20 shelf, Ideal for hotels, conferences, and event catering on a large scale. Designed around the standard Gastronorm GN1/1 pans. Simply load it with your chilled food and it will regenerate the food to a suitable temperature and automatically hold warm until ready to serve. Transfer the unit to the service area and plate up or load the pans into a Servery unit Bain-marie. Multi fan technology allows the food products to be regenerated and held in perfect condition.
These powerfully regen models use a unique power sharing function this allows each model to use two 13amp type power supplies.
DOWNLOADS
Specification

Key features
- Manual Operated Bulk Food Chillogen Trolley.
 - BBQ10C Designed to Chill and store.
10 x 65 mm deep containers within 90 minutes. - BBQ20C Designed to Chill and store
20 x 65 mm deep containers within 90 minutes. - Then Regenerate from Chilled.
 - Stainless Steel finish.
 - 200mm Castors 2 x Fixed and 2 x Swivel.
 - Unit comes complete with slide out cassette.
 - Capacity

| Model | GN1/1 Pans/Shelves |
|---|---|
| BBQ10 | 10 |
| BBQ20 | 20 |
![]()
Operating Modes
- Reheat food, hold hot food, transport food.


Electrical Specifications
BBQ10CM
- Rating - 5.75kW
 - Electrical Supply - 2 x 13amp

BBQ20CM
- Rating - 8.0kW
 - Electrical Supply - 16amp 3PH


Wiring Drawings
- Wiring drawing can be obtained by contacting Sales


Options
- 0576 Extra grid shelves.
